Buy underground water detector at an affordable price
With the increasing demand of human beings for water resources, finding and utilizing groundwater resources has become an important task. Underground water detector is the key tool to solve this problem, it uses the natural electric field for water source detection, eliminating the bulky power supply part in the traditional electric exploration, with simple operation, easy to carry, high accuracy, fast speed and flexible and diverse cloth pole and other advantages.
The characteristics of underground water detector
1. High precision: the sensor of the underground water detector has high precision and high sensitivity, which can detect the weak groundwater signals, so as to accurately locate the position of groundwater.
2. High efficiency: through specific algorithms and data processing technology, the underground water detector can quickly and accurately analyze the relevant information of groundwater and improve the exploration efficiency.
3. Reliability: the sensor and data processing unit of the underground water detector have been specially designed and manufactured, with high stability and reliability, and can work in all kinds of harsh environments.
4. Portability: the volume of underground water detector is small, easy to carry and operate, can be conveniently used in a variety of field environment.
Product Introduction
●10.1 inch touch screen operation
●Learn to operate in five minutes
●Real-time 2D, 3D and curve images2. Accurate and stable
●Solve the error of single channel multiple movement measurement.
●More than 10 channels are measured almost at the same time.
●Accuracy increased by more than 50%.
●Efficiency increased by 6 times3. Adjustable depth
●Choose the depth you need
●Provide a variety of depths for users to choose from within the maximum depth range.4. Three screen intercommunication
●Instrument screen,mobile phone screen,computer screen intercommunication.5. Intelligent and flexible
●1-30 channels optional and can be equipped with electromagnetic probe for TT probe measurement mode.6. Perfect after-sales
●Report by computer Expert online data analysis
7. Patented technology
●Obtained multiple invention patents
●Patent No.:ZL201310205318.9;ZL 201110454869.X;ZL201320054153.5;ZL201320303919.9
●Won the recognition of Shanghai High-tech Achievement Transformation Project
Technical Parameters | 100S | 200S | 300S | 400S | 600S | 800S | 1200S | 2000S | 3000S |
Detect Depth (m) | 0-100 | 0-200 | 0-300 | 0-400 | 0-600 | 0-800 | 0-1200 | 0-2000 | 0-3000 |
Measuring Mode(Intelligent frequency select) | 20 frequencies | 40 frequencies | 60 frequencies | 80 frequencies | |||||
Resolution | 2mv | 1mv | 0.5mv | 0.2mv | 0.1mv | 0.1mv | 0.01mv | ||
Repetitive Error | ±5%±2 bit | ±3%±2 bit | ±2%±2 bit | ±2%±2 bit | ±1%±1 bit | ±1%±1 bit | ±1%±0.5 bit | ||
A/D Swith | 16 bit 1Msps | 24 bit 1 Msps | |||||||
Power frequency | >80dB | ||||||||
Data Storage | Mobile phone or tablet PC (touching LCD 5-10.1” | ||||||||
Display | Blue tooth 4.0 | ||||||||
Mainframe Power | DC7.4V 3400mAh lithium battery | DC7.4V 6800mAh lithium battery | |||||||
Mainframe Power Consumption | 160mA | 230mA | 230mA | 360mA | 360mA | 360mA | 450mA | ||
Operating Temperature | -10℃-+40℃ | -20℃-+60℃ | -40℃-+70℃ | ||||||
Mainframe Size | 18.6*14.8*8cm | ||||||||
Mainframe Weight | 0.8kg | 0.9kg |
