D miningwell MW180 small portable water well drilling rig
MW180 multifunctional crawler well drill is a new,highly-effective ,energy-saving and multifunctional hydraulic drill and it is specialized in drilling well ,monitoring well, geothermal air-conditioning hole,grouting hole of the hydropower cofferdam,grouting hole for dyke seepage control and grouting hole for base enforcement ,surface mining ,anchorage .national defense project and other drilling operations;The drill rig is equipped with hydraulic motor rotation with a high power,propulsion and lifting of cylinder and down-hole impacter with high blast pressure,to realize high effectiveness of drilling footage and low energy consumption.
Advantages of Water Well Drilling Rig:
Engine: adopts the famous brand Guangxi Yuchai 64Kw turbocharged version
Crawler Driving Gear: the designed motor with a speed reduction gearbox prolongs the service life
Hydraulic oil pump: It uses parallel gearbox (which is a patent) to separate oil pump monomer, supply adequate power and distribute reasonable. The hydraulic system adopts unique design, which is easy to maintain and can lower the maintenance cost.
Rotary head device: integrated casting gearbox , dual motor power, large torque, durable, small maintenance costs
Drill chassis: the professional excavator chassis provides durability and strong load capacity, the wide roller chain plate causes small damage to the concrete pavement
Lifting force: patent designed composite arm with small size yet long stroke, double cylinder lifting, strong lifting capacity. The lift arm is installed with a limiter to protect cylinder and ensure the safety of work. Each hydraulic tubing is covered with a protective shell to effectively extend the service life of pipeline.
| Technical Parameters | MW-180 | MW-250 | MW-280 | MW-300 |
| Drill depth(m) | 180 | 250 | 280 | 300 |
| Drill diameter(mm) | 140-254 | 140-254 | 140-305 | 140-325 |
| Equipped Engine | YC 65kW | YC 70kW | YC 75kW | YC 85kW |
| Drill pipe diameter(mm) | φ76 φ89 | φ76 φ89 | φ76 φ89 | φ76 φ89 φ102 |
| Drill pipe length(m) | 1.5/2.0/3.0 | 1.5/2.0/3.0 | 1.5/2.0/3.0/6.0 | 1.5/2.0/3.0 |
| Swing speed(rpm) | 45-70 | 45-70 | 40-70 | 40-70 |
| Swing torque(N.m) | 3200-4600 | 3300-4500 | 4500-6000 | 5700-7500 |
| Rig lifting force(T) | 12 | 14 | 17 | 18 |
| Weight(T) | 5.2 | 4.1 | 7.6 | 7.2 |
| Dimension(mm) | 4000*1630*2250 | 4000*1800*2400 | 5900*1850*2360 | 4100*2000*2500 |
