liutech 25 bars screw compressor

COMPONENT LIST:

1.Screw Air end:European design and manufacturing,original atlas copco group ,high efficiency, low fuel consumption, excellent quality

2.Filter element/Separator elements/Oil filter/Diesel air filter–all of them Originial Germany Mann(Imported with original packaging)

Advanced technology,Reliable quality,High efficiency,Low fuel consumption!

Rated 4.8/5 based on 235 customer reviews
Share:
Content

Liutech belongs to Atlas Copco group, Liutech portable air compressors has the same quality as Atlas Copco portable air compressors.

Model Name LUY050-7 LUY085-14 LUY100-10 LUY100-12 LUY118-7 LUY120-14 LUY130-13 LUY150-15 LUY160-17 LUY235-9 LUY220-10
Working pressure, bar(psi) 7 (100) 14 (205) 10 (150) 12 (175) 7 (100) 14 (205) 13(190) 15 (220) 17 (250) 8.6 (125) 10 (150)
Flow, l/s|cfm|m3/min 83|177|5 142|300|8.5 167|353|10 167|353|10 197|420|11.8 200|424|12 217|460|13 250|530|15 267|565|16 396|830|23.5 367|780|22
Noise sound level (at 7m distance, dBA ) 70±3 79±3 79±3 79±3 79±3 83±3 83±3 83±3 83±3 79±3 79±3
Fuel tank capacity, l 67 185 120 120 120 180 180 250 250 300 300
Compressor oil capacity, l 8 25 26 26 26 23 30 32 32 55 55
Outlet valves, qty x size 3xG3/4 3xG3/4 1xG1  1/2 3xG3/4 1xG1  1/3 3xG3/4 1xG1  1/4 3xG3/4 1xG1  1/5 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4
Engine exhuast emission Tier 3 Tier 3 Tier 3 Tier 3 Tier 2 Tier 2
Engine maker Kubota Cummins Cummins Cummins Cummins Yuchai Cummins Yuchai Yuchai Cummins Cummins
Engine model V1505T 4BTAA3.9-C125 YC4A130-H311 YC4A130-H311 YC4A130-H311 YC6J175-H301 QSB5.9-C180-31 YC6A205-H300 YC6A240-H301 6CTA8.3-C260 6CTA8.3-C260
Engine power, Kw 33 93 96 96 96 129 132 151 176 194 194
Norminal engine speed, rpm 2950 2300 2300 2300 2300 2300 2400 2050 1950 2000 2000
Unloading engine speed, rpm 1950 1500 1400 1400 1400 1400 1400 1200 1200 1500 1500
Engine inspiration torbue charger torbue charger torbue charger torbue charger torbue charger torbue torbue torbue torbue torbue torbue
Length, mm 2960 3700 3700 3700 3700 4322 3000 4322 4322 3780 3780
Width, mm 1350 1790 1790 1790 1790 1950 2000 1950 1950 1950 1950
Height, mm 1420 1900 1900 1900 1900 1980 2190 1980 1980 2260 2260
Weight, kg 750 1650 1650 1650 1650 2250 1990 2550 2550 2990 2990
Model Name LUY200-10 LUY170-17 LUY180-19 LUY180-20 LUY210-17 LUY230-14 LUY250-12 LUY270-10 LUY290-9 LUY215-21 LUY290-23
Working pressure, bar(psi) 10(150) 17(250) 19 (275) 20(290) 17 (250) 14 (205) 12(175) 10(150) 8.6(125) 21(305) 23(335)
Flow, l/s|cfm|m3/min 336|706|20 286|600|17 300|635|18 300|635|18 350|745|21 386|815|23 417|885|25 450|955|27 486|1024|29 357|760|21.5 486|1020|29
Noise sound level (at 7m distance, dBA ) 79±3 79±3 83±3 83±3 83±3 79±3 79±3 79±3 79±3 79±3 83±3
Fuel tank capacity, l 300 300 300 325 300 470 470 470 470 512 500
Compressor oil capacity, l 55 55 55 60 55 65 65 65 65 75 75
Outlet valves, qty x size 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4
Engine exhuast emission Tier 2 Tier 2 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3
Engine maker Cummins Cummins Yuchai Cummins Yuchai Cummins Cummins Cummins Cummins Cummins Yuchai
Engine model 6CTA8.3-C260 6CTA8.3-C260 YC6A260-H300 QSB6.7-C260-32 YC6A260-H300 QSL8.9-C325-30 QSL8.9-C325-30 QSL8.9-C325-30 QSL8.9-C325-30 QSL8.9-C325-30 YC6MK340-H300
Engine power, Kw 194 194 191 191 191 242 242 242 242 242 250
Norminal engine speed, rpm 2000 2000 1900 2000 1900 2000 2000 2000 2000 2000 1900
Unloading engine speed, rpm 1500 1500 1200 1300 1200 1300 1300 1300 1300 1300 1300
Engine inspiration torbue torbue torbue torbue torbue torbue torbue torbue charger torbue charger torbue charger torbue
Length, mm 3780 3780 4404 4550 4404 5260 5260 5260 5260 5260 3850
Width, mm 1950 1950 1950 1770 1950 1800 1800 1800 1800 2040 2100
Height, mm 2260 2260 2296 2230 2270 2630 2630 2630 2630 2630 2690
Weight, kg 2990 2990 3330 3920 3330 4835 4835 4835 4835 4850 4100
