liutech diesel air compressor mining compressor

COMPONENT LIST:

1.Screw Air end:European design and manufacturing,original atlas copco group ,high efficiency, low fuel consumption, excellent quality

2.Filter element/Separator elements/Oil filter/Diesel air filter–all of them Originial Germany Mann(Imported with original packaging)

Advanced technology,Reliable quality,High efficiency,Low fuel consumption!

Rated 5/5 based on 218 customer reviews
Share:
Content

Liutech belongs to Atlas Copco group, Liutech portable air compressors has the same quality as Atlas Copco portable air compressors.

Model Name LUY200-10 LUY170-17 LUY180-19 LUY180-20 LUY210-17 LUY230-14 LUY250-12 LUY270-10 LUY290-9 LUY215-21 LUY290-23
Working pressure, bar(psi) 10(150) 17(250) 19 (275) 20(290) 17 (250) 14 (205) 12(175) 10(150) 8.6(125) 21(305) 23(335)
Flow, l/s|cfm|m3/min 336|706|20 286|600|17 300|635|18 300|635|18 350|745|21 386|815|23 417|885|25 450|955|27 486|1024|29 357|760|21.5 486|1020|29
Noise sound level (at 7m distance, dBA ) 79±3 79±3 83±3 83±3 83±3 79±3 79±3 79±3 79±3 79±3 83±3
Fuel tank capacity, l 300 300 300 325 300 470 470 470 470 512 500
Compressor oil capacity, l 55 55 55 60 55 65 65 65 65 75 75
Outlet valves, qty x size 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4 1*G2 1*G3/4
Engine exhuast emission Tier 2 Tier 2 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3 Tier 3
Engine maker Cummins Cummins Yuchai Cummins Yuchai Cummins Cummins Cummins Cummins Cummins Yuchai
Engine model 6CTA8.3-C260 6CTA8.3-C260 YC6A260-H300 QSB6.7-C260-32 YC6A260-H300 QSL8.9-C325-30 QSL8.9-C325-30 QSL8.9-C325-30 QSL8.9-C325-30 QSL8.9-C325-30 YC6MK340-H300
Engine power, Kw 194 194 191 191 191 242 242 242 242 242 250
Norminal engine speed, rpm 2000 2000 1900 2000 1900 2000 2000 2000 2000 2000 1900
Unloading engine speed, rpm 1500 1500 1200 1300 1200 1300 1300 1300 1300 1300 1300
Engine inspiration torbue torbue torbue torbue torbue torbue torbue torbue charger torbue charger torbue charger torbue
Length, mm 3780 3780 4404 4550 4404 5260 5260 5260 5260 5260 3850
Width, mm 1950 1950 1950 1770 1950 1800 1800 1800 1800 2040 2100
Height, mm 2260 2260 2296 2230 2270 2630 2630 2630 2630 2630 2690
Weight, kg 2990 2990 3330 3920 3330 4835 4835 4835 4835 4850 4100
