Portable screw air compressor MW110-10

Brand Name: D miningwell
Certification: CE, ISO
Minimum Order Quantity: 1 set
Packaging Details: 40HQ-20GP
Delivery Time: 15-20 days
Payment Terms: L/C, T/T, Western Union

This Diesel Screw Air Compressor Portable Compressor is especially developed for mine drilling rig , High reliablity，Easy operation and maintenance，Good power balance，Easy to transport.

Inquiry Now

Send Email

Product Introduction

Technical data

Application

Related cases

Product Introduction

This Diesel Screw Air Compressor Portable Compressor is especially developed for mine drilling rig , High reliablity，Easy operation and maintenance，Good power balance，Easy to transport.
It is very applicated for road construction ,concrete breaking , sand blasting...

Technical data

Specification of Portable Air Compressor
Model	MW110-10	MW141-15	MW192-17	MW200-21
Rated F.A.D(m³/min)	12.5	14	19	20
Rated pressure(bar)	10	15	17	21
Equipped Engine	110kW	141kW	191kW	191kW
Weight(T)	1470	1790	2400	4250
Dimension(mm)	235013001550	280015001820	285820041800	398518002200
Recommend diameter(mm)	80-110mm	115mm	138mm	152mm
