Piston air compressor W3.5-5

Brand Name: D miningwell
Certification: CE, ISO
Minimum Order Quantity: 1 set
Packaging Details: 40HQ-20GP
Delivery Time: 15-20 days
Payment Terms: L/C, T/T, Western Union

Diesel Portable Piston Air Compressor Mobile for Jack Hammer / Mining
1.Simple structure,light weight,easy to move .
2.Easy operating and maintenance.
3.High quality air delivery.
4.Superior technology,Low cost .

Product Introduction

Show details

Technical data

Related cases

Product Introduction

Diesel Portable Piston Air Compressor Mobile for Jack Hammer / Mining
1.Simple structure,light weight,easy to move .
2.Easy operating and maintenance.
3.High quality air delivery.
4.Superior technology,Low cost .
5.Valve plate and spring strip:made of special steel from Sweden and after special treatment.
6.Piston ring:special design;integral casting;excellent flexibility;lowest lubricating oil consumption
7.Cylinder:made of boron cast iron;wear resistant;special suitable for dusty condition
8.Cylinder cover:extrusion process adopted;streamlined external appearance;good heat emission performance.
9.High efficiency and low consumption.
10.Stable and smooth running with anti-vibration frame.
11.Professional design and Special manufacturing.
12.Energy saving.

Show details

Technical data

Model	Exhaust pressure (mpa)	Capacity (m³/min)	Cylinder (Dia*Qty)	Diesel engine/motor (kw/hp)	Dimension (cm)			Weight (kg)
Model	Exhaust pressure (mpa)	Capacity (m³/min)	Cylinder (Dia*Qty)	Diesel engine/motor (kw/hp)	Length	Width	Height	Weight (kg)
W-1.8/5	0.5	1.8	100*3	S1100	140	70	100	320
W-2/5	0.5	2	115*3	S1100	165	81	105	450
W-2.6/5	0.5	2.6	115*3	S1110	165	81	105	490
W-2.8/5	0.5	2.8	115*3	S1115	178	87	124	550
W-2.8/5-GD	0.5	2.8	115*3	15KW/20HP	178	87	124	550
W-3/5	0.5	3	125*3	S1115	180	90	130	600
2V-3.5/5	0.5	3.5	115*4	S1125	180	95	130	650
2V-3.5/5-D	0.5	3.5	115*3	18.5KW/25HP	180	95	130	650
2V-4/5	0.5	4	120*4	S1125	180	95	130	700
2V-4/5-D	0.5	4	120*4	18.5KW/25HP	180	95	130	700
W-1.8/7	0.7	1.8	100*3	S1100	165	81	105	450
W-1.8/7-D	0.7	1.8	100*3	11KW/15HP	165	81	105	450
W-2.6/7	0.7	2.6	125*3	S1115	178	87	124	480
W-2.6/7-D	0.7	2.6	125*3	15KW/20HP	178	87	124	480
W-3.2/7	0.7	3.2	125*3	S1125	196	90	125	550
W-3.2/7-D	0.7	3.2	125*3	18.5KW/25HP	196	90	125	550
W-3.2/7-ZD	0.7	3.2	125*3	18.5KW/25HP	196	90	125	550
